Product Specification

Model Number: D30*13.5mm EFL50mm

Usage: Optical

Shape: Spherical

Brand Name: MoWen

Material: K9+ZF2

Structure: Glued Lens

Description:

The lenses details is as follows:

Material:K9+ZF2

Diameter: 30mm

Radius:R1=29.2mm  R2= -23.6mm R3= -71.45mm

Focal length: 50mm

Back focal length:42.7mm

Tc:13.5mm(Tc1=11mm,Tc2=2.5mm)

Te:8mm

Centration:<3'

Dia tolerance:+0/-0.1mm

Thickness tolerance: +0.1/-0.1mm

Surface quality: 60/40

Coating: AR 400-700nm

Application:optical precision instrument

Note:Light shooting and different displays may cause the color of the item in the picture a little different from the real thing.
